27 thoughts on “Changing MP4 Pixel Aspect Ratio Using MP4Box”

1. “mp4box -add input.mp4#video:par=X:Y -add input.mp4#audio output.mp4”

   IS THIS SYNTAX ACTUALLY CORRECT?

   Reply ↓

   • ——————————————————————————-
     C:Program FilesMP4Box>mp4box -version
     MP4Box – GPAC version 0.4.5 (build 33 – Dec 11 2008) – compiled by Kurtnoise
     GPAC Copyright: (c) Jean Le Feuvre 2000-2005
     (c) ENST 2005-200X

     C:Program FilesMP4Box>mp4box -add “4-3 SAR Video.mp4″#video:par=4:3 -add “4-3
     SAR Video.mp4″#audio “16-9 PAR Video.mp4”
     IsoMedia import – track ID 2 – Video (size 480 x 360)
     IsoMedia import – track ID 1 – Audio (SR 44100 – 2 channels)
     Saving to 16-9 PAR Video.mp4: 0.500 secs Interleaving
     ——————————————————————————-

     Reply ↓

     • i added an extra space between the : and par command. took a fresh set of eyes to see it.

       F:video toolsmp4box>mp4box -add wrong.mp4#video: par=4:3 -add wrong.mp4#audio
       output_file.mp4
       Error – 2 input names specified, please check usage

       one thing i couldn’t get to work was the direct overwrite. but thats because the video was on track 2. i know you stated that such an error would occur if the wrong track was selected. is there a way to tell which track the video is on before processing?

       F:video toolsmp4box>mp4box -par 1=4:3 c:wrong.mp4

       Error: Bad Parameter

       F:video toolsmp4box>mp4box -par 2=4:3 c:wrong.mp4
       Saving c:wrong.mp4: 0.500 secs Interleaving

       Great post and thanks for the help!!

       Reply ↓
2. It extracts the audio because MP4Box didn’t seem to want to do that right. It also adds the subtitles from a SRT file into the MP4 Container.

   —–
   @echo off

   if [%1]==[] goto :eof
   :loop

   echo “Processing %~dpn1.mp4”

   :: Remove any existing mp4 file
   echo y | del “%~dpn1.mp4”

   :: *** Extract the parts
   :: Extract the Video
   :: *** We don’t need the video we will pull it from the mpg directly.
   :: mpegdemux -d -s 0xe0 %1 “C:tmp%~nx1.m2v”

   :: Extract the Audio
   mpegdemux -d -s 0xbd -p 0x80 –ac3 %1 “C:tmp%~nx1.ac3”

   :: ***Put the parts back together
   :: Video directly from MPG Andio from extracted AC3 subtitles from SRT file
   MP4Box -add “%~dpn1.mpg#video” -add “C:tmp%~nx1.ac3” -add “%~dpn1.srt” -new “%~dpn1.mp4”

   :: Delete the Parts
   ::echo y | del C:tmp%~nx1.m2v
   echo y | del C:tmp%~nx1.ac3

   ::Move the orig files into a backup folder
   move %1 “%~dp1Backup%~nx1”
   move “%~dpn1.srt” “%~dp1Backup%~n1.srt”

   shift
   if not [%1]==[] goto loop

   Reply ↓
3. SAR is 720/480 which is = 1.5

   PAR is 1.78/1.5 which is = to 1.186666666666667

   ¿?¿?¿?¿?

   Reply ↓

   • —Proper fraction—e.g., 2/5
     —Improper fraction (top-heavy fraction)—e.g., 5/2
     Equivalent fractions—e.g., 1/2 = 2/4 = 18/36 = 100/200
     Complex fraction—e.g., ½/¾
     Reducing fractions (simplifying the fraction)—e.g., 4/6 → 2/3

     A fraction in which the numerator and denominator are coprime—this means they have no factors in common other than 1—is said to be irreducible or in its lowest or simplest terms. Any fraction can be fully reduced to its lowest terms by dividing both the numerator and denominator by their GCD (greatest common divisor). For example, the greatest common divisor of 800 and 1080 is 40, therefore, the fraction 800/1080 can be fully reduced by dividing the numerator and denominator by 40:
     800/1080 = 20/27 or aspect-ratio-ly speaking 20:27

     The Euclidean algorithm (also called Euclid’s algorithm) can be used for computing the greatest common divisor (GCD), also known as the greatest common factor (GCF) or highest common factor (HCF).

     So, this is the math behind 20:27—displaying a 1920×800 picture as vertically-stretched 1920×1080:
     PAR = DAR ÷ SAR
     PAR = (1920/1080) ÷ (1920/800) = 1536000/2073600 = 20/27
     PAR = 20:27

     In the second example you brought up—displaying a 720×480 picture in 16:9 format:
     PAR = 16/9 ÷ 720/480 = 7680/6480 = 32/27
     PAR = 32:27

     Reply ↓

     • Rodrigo Polo on August 14, 2011 at 8:59 PM said:

       Hehehehe I feel so dumb, I assumed that the “/” was the division operator not the sign to indicate fractions, now it’s very clear, and thank you very very much for the long and very well done explanation, seriously, I appreciated.

       I did a JavaScript code to obtain the PAR having the SAR and the DAR:

       function getGCD(x,y){
       var w;
       while (y != 0){
       w = x % y;
       x = y;
       y = w;
       }
       return x;
       }

       function getPAR(SAR_width,SAR_height,ASPECT_width,ASPECT_height){

       /*
       var SAR_width = 720;
       var SAR_height = 544;

       var ASPECT_width = 16;
       var ASPECT_height = 9;
       */

       var DAR_width = SAR_width;
       var DAR_height = (SAR_width/ASPECT_width)*ASPECT_height;

       var BigPar_width = SAR_height * DAR_width;
       var BigPar_height = SAR_width * DAR_height;

       var Par_GCD = getGCD(BigPar_width,BigPar_height);

       BigPar_width = (BigPar_width/Par_GCD);
       BigPar_height = (BigPar_height/Par_GCD);

       return BigPar_width+’:’+BigPar_height;

       }

       console.log(getPAR(720,544,16,9));

       Reply ↓
     • Rodrigo Polo on August 14, 2011 at 11:05 PM said:

       Thanks a lot for the help, I have added a tool for this adding credits to you: http://tools.rodrigopolo.com/mp4box_aspect_fix/

       BTW check the other tools:
       http://tools.rodrigopolo.com

       Reply ↓
       • Komeil Bahmanpour on August 15, 2011 at 9:09 AM said:

         Nice work. Thanks.

         Reply ↓
4. Anonymous on March 20, 2012 at 6:53 AM said:

   I want to change the aspect ratio of some mp4 videos form 4:3 to 16:9 and I listen that MP4box command line can do this. I have downloaded MP4Box 0.4.6 and launch MP4Box.exe file contained in the zip folder. A ms dos window opened and closed forthwith and now i am stuck here that how to start the MP4Box command line. what’s the reason of this.

   Reply ↓
   • Rodrigo Polo on March 20, 2012 at 10:48 AM said:

     Google, Wikipedia and YouTube are your friends:
     http://www.youtube.com/watch?v=foYsmpDrYjY

     Just type what you want to learn!

     Reply ↓
   • Komeil Bahmanpour on March 20, 2012 at 12:32 PM said:

     The reason it immediately opens and closes is because it has nothing to do upon execution with no parameter to process when clicked upon. This is what happens:

     • Double-clicking on an exe file makes Windows Explorer (My Computer) attempt to run it.
     • If it is a Console application (i.e., no GUI window) the Explorer will call Command Prompt (cmd.exe) passing the Console application as a parameter (e.g., %SystemRoot%system32cmd.exe “D:MP4Box 0.4.6MP4Box.exe”).
     • Hereafter, it’s the Command Prompt who’s in control of the execution. MP4Box.exe requires its own parameters to process, and with nothing for MP4Box.exe to do, it’s soon ended, resulting the DOS-like window to close immediately.

     So, to be able to see what’s really happening before the window is being closed, you’ll have to open a command prompt, navigate the command processor to MP4Box location, and then run it:

     • Click on Command Prompt, or simply run cmd.exe.
     • Using CD (change directory) command, navigate to the drive/folder you have previously extracted the files for MP4Box. A /d switch is required if you’re changing the drive comparing to your current Prompt drive. Enclose the path in double quotations if it contains any space character (e.g., cd /d “D:MP4Box 0.4.6”).
     • Now, enter the executable name and press enter (e.g., MP4Box).
     • The file executes, and you can see the result. Now try it with parameters discussed above in the article.
     • After you’re done with it, close the Shell using the exit command.

     Now, if you’re using Windows 7, there’s a faster shortcut into opening and navigating a CMD into a specific folder: Navigate to that folder in Windows Explorer (My Computer). While holding the shift key down, right-click on a blank portion of the folder content (or even as a faster alternative, use Shift+Menu on the keyboard). Amazingly, the popup menu contains different items, including an Open command windows here. Try that one.

     Reply ↓
5. RaVen on April 30, 2012 at 8:33 PM said:

   THANK YOU SO MUCH both Komeil and Rodrigo Polo for your excellent effort to provide with such a precious tutorial. Rodrigo by the way your java tool (aspect fix) made things soooo much easier plus it works like a charm!!!

   Thanks again so much….you both kick ass !!

   P.S. only problem I have on the new changed aspect mp4 file is that when you skip forward the video it gets blockie – big pixel blocks come up in different areas on the screen while playing the video after fast forwarding it. Any idea how to fix this will be very appreciated. Thank you

   Reply ↓
   • Komeil Bahmanpour on May 6, 2012 at 2:06 AM said:

     Sounds like a key frame problem.

     In video compression, a keyframe (aka intra-frame) is a frame in which a complete image is stored in the data stream. In order to greatly reduce the amount of information stored compressedly, only changes that occur from one frame to the next are stored in the data stream.

     Except for keyframes themselves, because video compression only stores incremental changes between frames, it is not possible to easily fast forward or rewind to any arbitrary spot in the video stream—since the data for a given frame only represents how that frame was different from the preceding frame.

     Now, your video with the blocks; sounds like your video player has a bug in its rewind/fast forward algorithm as it is not able to determine all the proper changes comparing to both the keyframe and prior frames between the sought frame itself and its preceding keyframe.

     If the problem is only with the fixed clip and not with the one with the wrong ratio, then it’s the player algorithm’s fault. Try another player (software / home cinema system). Be advised cheap home systems tend to ignore the ratio flag. Home Blu-ray Disc players based on MediaTek MT8555 are a good example of those respecting the flag. (Pioneer BD players BDP-LX55 & BDP-440)

     Reply ↓
     • RaVen on May 7, 2012 at 6:46 AM said:

       I use VLC where I noticed that issue as well but in Gom player it plays the file like the file its corrupt with distorted image during play and the most important is that the 16:9 file that was changed to 4:3 is still being shown into 16:9 plus after changing the aspect ratio it adds those corrupt issues in the file.
       Do you know if there is any way to fix this in the MP4Box or do you know any other aspect changing program without encoding the mp4 file?
       Or the third alternative for a solution would be if you know any other program that is 100% compatible with the MP4Box converted files and can play-rewind-fast forward the changed aspect file normally without any bad algorithm issues which cause distorted image during play.
       What do you suggest?

       Thank you

       Reply ↓
       • Rodrigo Polo on July 3, 2012 at 11:45 PM said:

         This is actually an encoding issue, to be able to “scrub” you have to encode your video specifying a keyframe rate, I use one per second so I can scrub between seconds, about the aspect ratio, once you manage to fix the aspect ratio with MP4Box it works, it does, if it doesn’t work with your video maybe you are miscalculating the aspect ratio, an easy way I use to know the right aspect ratio is by playing the video on VLC, changing the video to the wright aspect ratio, taking a snapshot and then I check the dimensions of the snapshot to have the DAP (display aspect ratio) then knowing the SAR (source aspect ratio) by checking the video information with MediaInfoRaw I do the math to know the PAR (picture aspect ratio).

         Reply ↓
6. PacoH on August 14, 2014 at 9:48 AM said:

   Hey Komeil, thanks for this article. I have some videos I downloaded from Youtube that have the wrong aspect ratio. I opened them with MplayerX (I’m on a Mac) and determined that they should be 5:4 and not the original 16:9. I first tried using ffmpeg to simply change the aspect ratio in the header but some of them did not display the change even though it was there. I quickly learned that changing the PAR with mp4box was much more reliable so I tried it using your math in Excel, formatting the result to a fraction. That worked great. But I wanted a bash script to do all the work for me. That became a bit of a project since I didn’t know how to get the original SAR and didn’t know how to do the math in bash. I tried various methods I found on the net to get the SAR. I finally settled on using the CLI version of mediainfo:

   mediainfo –Inform=”Video;%DisplayAspectRatio/String%” “video file.mp4”

   This gives:

   16:9

   Great, so I set a variable to the output. Next, the math. I can’t believe it but I struggled with this a bit before it dawned on me that it was ridiculously simple. I see that you and a few other people went through similar contortions before you settled on the same solution that I did. Well almost… I first tried just using the decimal PAR but, though mp4box did not complain about it, it did not change the DAR. So I did some googling and found really nothing useful for bash. I finally found the perl module Math::BigRat (funny name huh?) that will convert a decimal value to a reduced fraction and return numerator and denominator. This worked great but I couldn’t find any convenient way to incorporate it into a bash script and pass the values to the script. I went to bed tired and ‘slept on it’. When I awoke, the simple, obvious (funny how the obvious eludes us sometimes) solution was simply to get numerator and denominator using high school algebra, similar to what you show in one of your replies, which I hadn’t read yet. I use the SAR and the desired DAR, instead of the pixel height and width as you do, to get the PAR for mp4box. I don’t worry about reducing it because it is too much trouble and I think mp4box can handle it anyway.

   PAR = DAR / SAR
   nPAR / dPAR = (nDAR / dDAR) / (nSAR / dSAR) = (nDAR / dDAR) * (dSAR / nSAR)

   nPAR = nDAR * dSAR
   dPAR = dDAR * nSAR

   Where ‘n’ refers to ‘numerator’ and ‘d’ to ‘denominator’.

   This is what I needed.

   So here is my bash script, ‘changeaspect.sh’, which reads the desired DAR from the command line, loops through all the files in a directory, gets the SAR of each file, changes the DAR using mp4box, and outputs the new file, with the DAR appended to its name, to a subdirectory with the new DAR as its name:

   shopt -s nullglob

   IFS=’:’ read -a DAR <<< "$@" # read DAR from command line
   nDAR=${DAR[0]} # numerator
   dDAR=${DAR[1]} # denominator

   outdir="${nDAR}to${dDAR}"
   if [ ! -d "$outdir" ]; then
   mkdir "$outdir"
   fi

   for f in "$arg"*.{mp4,avi,3gp,mpg,mpeg,vob,dat,vcd,svcd,ts,m2t}
   do
   p="${f##*/}" # file
   n="${p%.*}" # name
   e="${p##*.}" # extension
   i=`mediainfo –Inform="Video;%DisplayAspectRatio/String%" "$p"` # get original DAR:
   echo ''
   echo "Original DAR: $i"
   echo ''
   IFS=':' read -a SAR <<< "$i"
   nSAR=${SAR[0]} # numerator
   dSAR=${SAR[1]} # denominator

   nPAR=$(($nDAR * $dSAR)) # numerator – nPAR = nDAR * dSAR
   dPAR=$(($dDAR * $nSAR)) # denominator – dPAR = dDAR * nSAR

   outfile="$n (${nDAR}to${dDAR}).$e"
   outpath="$outdir/$outfile"
   if [ -e "$outpath" ]; then
   rm "$outpath"
   fi

   mp4box -new -add "$p#video:par=$nPAR:$dPAR" -add "$p#audio" "$outpath"

   echo ''
   i=`mediainfo –Inform="Video;%DisplayAspectRatio/String%" "$outpath"`
   echo "PAR: ${nPAR}:${dPAR}"
   echo "Modified DAR: $i"
   done
   echo ''

   Even though '-new' causes mp4box to overwrite existing files, I had to delete them to get consistent results.

   This is run from the command line:

   $ changeaspect.sh 5:4

   Example output:

   Original DAR: 16:9

   IsoMedia import – track ID 1 – Video (size 1280 x 720)
   IsoMedia import – track ID 2 – Audio (SR 44100 – 2 channels)
   Saving 5to4/James Potter and the Hall of Elders' Crossing Part 1 (HQ) (5to4).mp4: 0.500 secs Interleaving

   PAR: 45:64
   Modified DAR: 5:4

   Original DAR: 16:9

   IsoMedia import – track ID 1 – Video (size 1280 x 720)
   IsoMedia import – track ID 2 – Audio (SR 44100 – 2 channels)
   Saving 5to4/James Potter and the Hall of Elders' Crossing Part 2 (HQ) (5to4).mp4: 0.500 secs Interleaving

   PAR: 45:64
   Modified DAR: 5:4

   …

   I only tried this on mp4 files so far so I don't know how it will behave on the other container formats, but I included all the formats you mentioned for thoroughness. This also assumes there is only one video track.

   You could use this script with cygwin on Windows I assume, with some modifications.

   Reply ↓
7. Kevin Chan on August 15, 2017 at 1:40 AM said:

   Hey Komeil, thanks for this article. I have some JPG files want to combine it into MEPG-4. Please advise how can we use MP4BOX to do it.

   Reply ↓
8. Nicholas on December 28, 2018 at 12:19 PM said:

   I didn’t know about the -par argument. Thanks to this I was able to fix my issues. Had a weird mpg video that wasn’t encoded correctly and when I tried to put it into an mp4, it kept flattening the video. My fix ended up being to specify -par 1=1:1 and now the video is coming out without being flattened. This was driving me crazy for months. Now I have to go back and re-encode a bunch of similarly badly encoded videos this same way. Cause the other way I was doing it was leading to videos working only on certain programs.

   Reply ↓
9. Nick on January 10, 2019 at 2:57 PM said:

   Thanks! Very helpful. I haven’t found this info presented this clearly anywhere else online.
